Invert Mud Plants

SERVICING CLIENTS IN CANADA & USA SINCE 2018

Edson Alberta Invert Mud Plant

•High Shear Mixing Technology – (reduced product concentrations, increased fluid properties, reduced mixing times)

•2 x 100 HP Motors powering two (2) 8x6x14 Mission Magnum Centrifugal Pumps

•4 x 60 HP High Shear Turbine Motors

•Specialty designed internal piping with multiple jet nozzles for maximum mixing

•Bulk Hopper System – Barite up to 1.5 MT Totes (HSE) - allowing for quick and efficient weight up when required.

•Dust Collection System (HSE)

•Indoor Heated Mixing Room (HSE)

•Mix Tank Load Cells – Accurate Product Additions and Concentration Tracking

•High Level Fluid Level Alarm (HSE) – spill prevention

•Pipe connected to existing fluid tank farm / storage facility allows for offload inbound base oil directly into storage tanks

•Ability to mix various base oil’s sourced from various tanks within the tank farm

•Weighted and Unweighted Invert Mixing Options

•Toll Blending Services

•Onsite Invert Mud Testing Lab - including Closed Cup Flash Point Testing

•Ability to blend formulations using various customer supplied Base Oil’s & Chemical Products

•Inbound Rail Car and Truck Capability

•7 day per week operations

• Used Invert Marketing, Sales and Purchasing Services

Sexsmith Alberta Invert Mud plant

Sexsmith Facility

2 x separate mix tanks

2023 Mix Plant Upgrade:

65m3 Mix Skid
Ability to mix custom invert formulations (unweighted to >1500kg/m3)
High Shear Mixing Technology – (reduced product concentrations, increased fluid properties, reduced mixing times)
•2 x 100 HP Motors powering two (2) 8x6x14 Mission Magnum Centrifugal Pumps
•4 x 60 HP High Shear Turbine Motors
•Specialty designed internal piping with multiple jet nozzles for maximum mixing
~220MT Bulk Barite Storage
Indoor Mix Room, office and testing lab
Various circulation pumps and motors to facilitate fluid transfers within facility

Sexsmith - Mix Plant - Original

55m3 Invert Mix Tank
13m3 High Shear Mix Tank - for additional Shear and Circulation Capacity
2 x 75HP motors, operating two (2) 6x5x11 Mission Centrifugal Mud Pumps.
3 x 3” Mud Gun Lines (360 degree rotation) each with high shear induction Nozzles
Dual (2) x High Capacity Mix Hoppers for dry and liquid product additions.
Bulk Barite Hopper / Auger System – (Handles Barite totes up to 1.5MT).
Dust Collection System.
Pre Fab System to allow mixing in all weather conditions.
High Fluid Level Alarm (spill prevention).
Onsite OBM testing Lab.
Fully staffed – available for 7 day per week operations.
Storage Tank Circulation - multiple pumps and motors to facilitate tank rolling and circulation.
Pipe connected to existing fluid tank farm / storage facility allows for offload inbound base oil directly into storage tanks
Ability to mix various base oil’s sourced from various tanks within the tank farm
